SW24/1.5 is linear LED strip with 172 lm/ft @ 3000K provides even, consistent color.
SW24/1.5 is linear LED strip with 172 lm/ft @ 3000K provides even, consistent color.
SW24/1.5 is an energy-efficient 24-volt, 1.5-watt/foot strip features 6 diodes per 1” cut point and is available in CCTs of 2000K, 2200K, 2400K, 2700K, 3000K, 3500K, and 4000K. CCTs 2200K and greater meet or exceed Title 24 and JA8.
SW24/1.5 linear led strips
SW24/1.5 linear led strips
SW24/1.5
SW24/1.5
SW24/1.5
SW24/1.5

SW24/1.5

LED Strips - Static White
1-Bin, 1-Step
Conformite Europeenne
UL Listed LED lighting products
RoHS LED lighting product
JA8 Lighting
5 Year Warranty
Buy American Cove Waiver Approved Lighting Products
Designed In USA
Declare Label Approved Lighting
UKCA Certification

172 lm/ft @ 3000k, 6 diodes per 1" cut point.

  • One bin, one step LED strip for even, consistent color output
  • Delivers 172 lumens per foot @ 3000K
  • Energy-efficient 24V system 1.5 watts/foot
  • Equipped with 6 diodes per 1" cut point for excellent light uniformity
  • CCT Options: 2000K, 2200K, 2400K 2700K, 3000K, 3500K, 400K
  • CCTs 2200 and greater meet or exceed Title 24 and JA8 standards
  • Thermal specifications:
    • Ambient operating temperature: -4°F to 150°F
    • Installation temperature: 50°F to 100°F
    • Storage Temperature: -4°F to 140°F
  • Calculated L70 lifespan: 70,000 hours
  • Pair with aluminum LED extrusion to create a custom linear fixture
More About SW24/1.5
Technical InformationVideosRelated Products

Technical Information

Watts per Foot 1.5
Rated Dry IP20, Damp IP54, Wet IP67
LED Type Static White
Cut Length 1" increments
LEDs per Cut Length 6 diodes
Environment Indoor/Outdoor
CCTs 2000K, 2200K, 2400K, 2700K, 3000K, 3500K, 4000K
Certifications UL Listed, CE, 1 Bin 1 Step, RoHS, JA8-2016, Declare, UKCA
Compatible App SCENE Dongle
Connector Wire Bare Wire (Standard 24"), Barrel, Close End (No feed), Connector 6", Connector 24"
CRI 98 at 3000K
Warranty 5 year
