Close-up view of the SW-HE+24/3.0 LED strip radiating a 3000K warm light intensity at 587 lm/ft, showcasing its 9 diodes spaced evenly within a 2-inch segment.
Close-up view of the SW-HE+24/3.0 LED strip radiating a 3000K warm light intensity at 587 lm/ft, showcasing its 9 diodes spaced evenly within a 2-inch segment.
Detailed depiction of the SW-HE+24/3.0 LED tape, a 3.0W/ft, 24-volt lighting solution, emphasizing its 9 diodes per 2-inch cutpoint and its adaptability for both dry and wet locations, extendable up to 196 inches.
SW-HE+24/3.0
SW-HE+24/3.0
SW-HE+24/3.0 linear led strip

SW-HE+24/3.0

LED Strips - Static White High Efficacy Plus
Conformite Europeenne
UL Listed LED lighting products
RoHS LED lighting product
5 Year Warranty
Buy American Cove Waiver Approved Lighting Products
Designed In USA
Declare Label Approved Lighting
UKCA Certification

587 lm/ft @ 3000k, 9 diodes per 2" cut point.

  • 24-volt, 3.0 watts/foot linear LED strip
  • Designed for energy-efficient performance in a variety of environments
  • 2” cut points for precision customization
  • Field-cuttable up to 196” for tailored installation
  • Dry and wet-rated for indoor and outdoor applications
  • Thermal Specifications:
    • Ambient operating temperature: -13°F to 145°F
    • Installation temperature: 50°F to 100°F
    • Storage temperature: -13°F to 176°F
  • Calculated L70 lifespan: 66,000 hours
  • Pair with aluminum LED extrusion to create a custom linear fixture
More About SW-HE+24/3.0
Technical InformationVideosRelated Products

Technical Information

Watts per Foot 3
Rated Dry IP20, Wet IP67
LED Type High Efficacy Static White
Cut Length 2" increments
LEDs per Cut Length 9 diodes
Environment Outdoor
CCTs 2700K, 3000K, 3500K, 4000K
Certifications UL Listed, CE, RoHS, Declare, UKCA
Compatible App SCENE Dongle
Connector Wire Bare Wire (Standard 24"), Barrel, Close End (No feed), Connector 6", Connector 24"
CRI 92 at 3000K
Warranty 5 year
