SW-HE24/3.0
LED Strips - Static White High-Efficacy
407 lm/ft @ 3000k, 8 diodes per 2" cut point.
- One bin, one step LED strip for consistent, color output across projects
- Delivers exceptional photometric performance
- Rated at 3.0 watts/foot, 24 volts
- Contains 8 diodes per 2” cut point for smooth, even illumination
- Dry and wet-rated for use in a wide range of environments
- Field-cuttable up to 384” for custom-length installations
- CCTs: Available in a range from 2000K to 4000K
- Thermal Specifications:
- Ambient operating temperature: -4°F to 145°F
- Installation temperature: 50°F to 100°F
- Storage temperature: -4°F to 140°F
- Calculated L70 lifespan: 66,000 hours
- Pair with aluminum LED extrusion to create a custom linear lighting fixture
More About
SW-HE24/3.0
Technical Information
| Watts per Foot | 3 |
| Rated | Dry IP20, Damp IP54, Wet IP67 |
| LED Type | High Efficacy Static White |
| Cut Length | 2" increments |
| LEDs per Cut Length | 8 diodes |
| Environment | Indoor/Outdoor |
| CCTs | 2000K, 2200K, 2400K, 2700K, 3000K, 3500K, 4000K |
| Certifications | UL Listed, CE, 1 Bin 1 Step, RoHS, JA8-2016, Declare, UKCA |
| Compatible App | SCENE Dongle |
| Connector Wire | Bare Wire (Standard 24"), Barrel, Close End (No feed), Connector 6", Connector 24" |
| CRI | 98 at 3000K |
| Warranty | 5 year |
