LED aluminum extrusion showcasing a range of beam angles and lens options in a sleek design
LED aluminum extrusion showcasing a range of beam angles and lens options in a sleek design
TORQ DIMENSIONS
TORQ
LED extrusion, available in various finishes and lens options, designed for optimal beam control in surface or recessed installations
TORQ
Versatile LED extrusion solution for both surface mounted and recessed lighting applications.
TORQ
TORQ
TORQ
TORQ

TORQ

Field Assembled LED Extrusion - Surface & Recessed Applications
RoHS LED lighting product
WhiteOptics
Declare Label Approved Lighting
Red List Free Approved Lighting
10 Year Warranty

Surface mount aluminum extrusion

  • QTL's most popular LED extrusion
  • Suitable for surface-mounted or recessed installations
  • Compatible with an optional mounting tray to achieve specific beam angles
  • Beam Angle Options (with mounting tray): 12°, 40°, 60°, 70°
  • Lens Options: Clear, Frosted, Polar, Diffused, and Optical
  • Seamlessly integrates with WhiteOptics® to increase light output by 5–52%
  • Offered in custom cut pieces
  • Available in maximum length sections
  • Also, available as fully assembled linear LED fixture

*See the Spec Sheet for WhiteOptics Photometric data details.

More About TORQ
Technical InformationVideosRelated Products

Technical Information

Finish Satin, Black, Bronze, Custom
Mounting Stainless Steel, Magnet, Low Profile Magnet
Photometric Performance Clear 60°, Clear 70°, Optical 12°, Optical 40°
Warranty 10 year
Certifications RoHS, Declare, Declare Red List Free
Environment Indoor/Outdoor
LED Light Engine Warm Dim, Static White, Static White High Efficacy, Dynamic White, Dynamic White High Efficacy, Static Color, RGB, RGBW High Efficacy
Length 1" increments from 1" - 98.43"Tolerance +0.0"/-0.5"
Lenses Optical, Clear, Frosted, Polar, Diffused
Material Aluminum Housing
Product Applications Surface Mount
